HIGHLIGHTS
TECHNOLOGY
- APDV Engine- Advance Pro Digital Variable Ignition System
- Fuel Saving i3S Technology
HIGHLIGHTS
FEATURES
- Convenient Power Start
- Exciting Body Graphics
- Stylish Alloy Wheels
- USB Mobile Charger
COLOURS
Gold Black (SE)
Candy Blazing Red
HERO AND ITS PRICE
Engine
Transmission & Chassis
Suspension
Brakes
Wheels & Tyres
Electricals
Dimensions
Type
Air cooled, 4 - Stroke Single Cylinder OHC
Displacement
97.2 cc
Max Power
6.15 kW (8.36 Ps) @ 8000 rpm
Max Torque
0.82 Kgfm (8.05 Nm) @ 5000 rpm
Compression Ratio
9.9:1
Starting System
Kick start / Self start
Ignition
DC - Digital CDI
Clutch
Multi-plate wet Type
Gear box
4 Speed Constant Mesh
Chassis Type
Tubular Double Cradle Type
Front
Telescopic Hydraulic Shock Absorbers
Rear
Swing Arm with 5 Step Adjustable Hydraulic Shock Absorber
Front Brake
Internal Expanding Shoe Type (130 mm) - Non Asbestos type
Rear Brake
Internal Expanding Shoe Type (130 mm) - Non Asbestos type
Tyre Size Front
80/100-18 WC 47P (Tubeless)
Tyre Size Rear
80/100-18 WC 54P (Tubeless)
Battery
12V-3 Ah MF (ETZ4)
Head Lamp
12V - 35/35 W-Halogen Bulb (MFR)
Tail/Stop Lamp
12V-5/10W (Multi-Focal Reflector)
L X W X H
2000 mm X 720 mm X 1040 mm
Wheelbase
1230 mm
Ground Clearance
159 mm
Kerb weight
112.3 kgs (Electric Start)
Max Payload
130 kgs
Fuel Tank Capacity
10 Litres
Reserve
1.1 Litres (Usable Reserve)
